-1/2.8′ Progressive Scan CMOS
-Max resolution 1920×1080@25fps, 2MP
-4mm F1.0 lens, Warm light 30m
-WDR 140dB, VCA(Video Content Analysis)
-Smart H.265/H.265/H.264, Onvif, Slink
-Microphone, Speaker, TF Card slot
-12V DC, PoE, Metal, IP67
24/7 dark fighter full color technology, low lighting environments are no longer a problem for security. F1.0 large aperture, 4x incoming light than F2.0 aperture. F1.0 large aperture lens, more advanced sensor that ultra series of full color camera is able to see in full vibrant, and true color all night long. It is also what really makes this series camera stand out from other surveillance.
2MP Network Black Light Ultra Low illumination Full Color 30m Warm Lights Fixed Bullet Camera
Model: SE-MS2T21A
-1/2.8″ Progressive Scan CMOS
-2MP(1920×1080)@25fps
-F1.0 4mm lens
-Warm lights up to 30 meters
-WDR 140dB
-Video Analysis(Area intrusion, Absent alarm, Loitering, Line crossing detection, Vehicle illegal parking, Retrograde detection)
-Built in Human detection algorithm, carry out human detection independently
-Detection frame 5fps, detect 5-10 people at the same time
-S.265/H.265 high efficiency compression, save bandwidth and storage space
-Support 3DNR and mirror
-Support auto electronic shutter to match different surveillance environment
-Support HTTPS transmission with password
-Support ONVIF, SLINK, Email, NTP service
-Force password revise when initial startup to ensure the password security
-Support Mobile Application, Lite IMS and Professional IMS 4.0 central management software
-IP67, Metal, DC12V, PoE
| Camera | |
| Sensor | 1/2.8″ Progressive Scan CMOS |
| Lens | 4mm, F1.0 |
| Lens interface | M12 |
| Focal Length & FOV | 4mm, horizontal FOV 95.5°, vertical FOV 50.8°, diagonal FOV 114.5° |
| Min. Illumination | Color: 0.001Lux/F1.0, AGC ON, B/W: 0Lux(Warm light ON) |
| Electronic shutter | 1/5 s to 1/100,000 s |
| S/N Ratio | ≥ 52 dB |
| Day/ Night mode | Auto, Day, Night, Custom |
| Warm light | 25-30m |
| DWDR | DWDR(off/low/middle/high) |
| IR Led Control | Auto/Manual/Off |
| DNR | Off/Low/Middle/High/Higher |
| Defog | Off/Low/Middle/High |
| Mirror | Off/ Horizontal Mirror/Vertical Mirror/180 degree flip |
| Image Setting | Brightness, Contrast, Sharpness, Saturation, Chroma |
| General Events | |
| Motion Detection | Support day arming /night arming mode; Support to configure the customized arm time by week, with 4 time periods per day |
| Support full screen / area detection | |
| Linkage setting support: upload mail/voice broadcast alarm/alarm light | |
| Obstruction Alarm | Support day arming/night arming mode; Support to configure the customized arm time by week, with 4 time periods per day |
| Support one detection area | |
| Support linkage actions: Upload mail, Voice broadcast alarm, Light alarm | |
| Privacy mask | Support four areas setting |
| VCA | |
| Support one detection area, and can draw a multi deformation detection area | |
| (Detection area is consist of 6 points) | |
| Support video stream overlay detection frame | |
| Support specified target type detection: human, vehicle (non-motor vehicle also can be detected) | |
| Support linkage actions: Upload mail, Voice broadcast alarm, Light alarm | |
| Line-crossing Detection | Support day arming /night arming mode; Support to configure the customized arm time by week, with 4 time periods per day |
| Support one detection line, supports detection directions: A->B | |
| Support video stream overlay detection frame | |
| Support specified target type detection: human, motor vehicle (non-motor vehicle also can be detected) | |
| Support linkage actions: Upload mail, Voice broadcast alarm, Light alarm | |
| Wandering/Loitering | Support day arming /night arming mode; Support to configure the customized arm time by week, with 4 time periods per day |
| Support one detection area, and can draw a multi deformation detection area | |
| (Detection area is consist of 6 points) | |
| Support video stream overlay detection frame | |
| Support wandering time setting(10~3600S) | |
| Support linkage actions: Upload mail, Voice broadcast alarm, Light alarm | |
| Absent Alarm | Support day arming /night arming mode; Support to configure the customized arm time by week, with 4 time periods per day |
| Support one detection area, and can draw a multi deformation detection area | |
| (Detection area is consist of 6 points) | |
| Support video stream overlay detection frame | |
| Support absent time setting(10-3600S) | |
| Support at least 1-3 people on duty | |
| Support linkage actions: Upload mail, Voice broadcast alarm, Light alarm | |
| Vehicle Illegal Parking | Support day arming /night arming mode; Support to configure the customized arm time by week, with 4 time periods per day |
| Support one detection area, and can draw a multi deformation detection area | |
| (Detection area is consist of 6 points) | |
| Support video stream overlay detection frame | |
| Support illegal parking time setting(10-3600S) | |
| Support linkage actions: Upload mail, Voice broadcast alarm, Light alarm | |
| Vehicle Retrograding | Support day arming /night arming mode; Support to configure the customized arm time by week, with 4 time periods per day |
| Support one detection area, and can draw a multi deformation detection area | |
| (Detection area is consist of 4 points) | |
| Support video stream overlay detection frame | |
| Supports four detection directions, detection line support B->A direction | |
| Support linkage actions: Upload mail, Voice broadcast alarm, Light alarm | |
| Audio & Video Encoding | |
| Video Encode Standard | Smart H.265/H.265/H.264 |
| Encoding Feature | Main stream: 2MP(1920×1080)25fps |
| Sub stream:D1(720*576),VGA(640*480),Q720P(640*360),CIF(352*288)@25fps | |
| Video Code Rate | Fixed code rate, variable code rate(Main stream code：160Kbps-4000kbps） |
| Video Type | Composited stream/video stream |
| Audio Standard | G.711u /G.711A 64Kbps |
| Network Function | |
| Protocol | TCP/IP, UDP, HTTP, HTTPS, DHCP, RTSP, RTP, IPv4, DDNS, NTP, PPPOE, UPNP, SMTP, DNS, QoS |
| Connection Protocol | ONVIF, SLINK, HIK, TST |
| Preview Video Quantity | 10PCS |
| Security Mode | Authorized user name and password, HTTPS with password, AES connecting with password, |
| RTSP verification | |
| Motion Detection | Setup detection area, multi-level sensitivity available to setup |
| Obstruction Alarm | Support 1 area setting |
| Privacy Mask | Support 4 area privacy mask |
| Schedule Linkage | Upload email/FTP upload picture, Arming time support day arming/night arming/cutsomized arming |
| Anomaly Inspection | Support network disconnection alarm, IP conflict alarm, illegal access alarm |
| Character Overlay(OSD) | Support time OSD/Title OSD, multi-line OSD (two lines), Main stream font support 12-60pt, sub stream font support 12-36pt |
| Interface | |
| Network Port | RJ45 10M/100M network self-adjustable |
| TF Card slot | Support, max 512G |
| Audio input | Microphone |
| Audio output | Speaker |
| Alarm input | / |
| Alarm output | / |
| General | |
| Power Supply | DC12V, 0.6A, max. 6W; PoE: 802.3af, max. 7W |
| Protection | IP67, Metal |
| Size | 181.08(L)x70.17(W)x58.80(H)mm |
| Working Temperature | -30°C ~ 60°C |
| Working Humidity | 0%~90% |
