| Camera | |
| Image Sensor | 1/3" 5MP Progressive scan CMOS |
| Effective Pixels | 2560x1920, 5MP |
| Min. illumination | 0Lux/F1.4 (IR ON) |
| Electronic Shutter | Auto/manual (1/25s-1/10000s) |
| Day/Night | Auto/Color/ B/W EXT |
| Lens | 3.6mm |
| IR Distance | 20m |
| Video Parameter | DWDR, Mirror, 3DNR, Sharpness, Brightness |
| Protection | IP66 |
| Power supply | POE, DC12V |
| NVR | |
| Video Input | 4CH |
| Video Compression | H.265 |
| Video Input Resolution | 5MP/4MP/1080P/960P/720P/D1/VGA/4CIF/DCIF/2CIF |
| Video Output | VGA/HDMI sync output, 1920×1080,1440×900,1280×1024,1366×768,1024×768,800×600 |
| Bit Rate | 16-8000Kbps |
| Image Display | 1/4/6/8/9 screens |
| Snapshoot | Support(BMP) |
| Motion Detection | 396(22*18)areas available to setup and multi sensitivity adjustable |
| Video Frame Rate | 1-30fps |
| Record Mode | Manual/Alarm/MD/Regular |
| Playback Synchronic | Support 1CH 5MP/4MP/3MP, 4CH 1080P or 8CH sub-stream sync playback |
| Search Method | Time, Calendar, Event, Channel |
| Video Playback | Start, Stop, Fast play,Slow play, Frame play, Snapshoot, Full screen, Precise playback |
| Backup location | Local HDD, Network |
| Backup Method | Network, USB storage device, USB recorder |
| Network Protocol | TCP/IP, HTTP, DDNS, SMTP(SSL), DHCP, PPPOE, UPNP, NTP, P2P, ONVIF |
| Connect protocol | Slink, ONVIF |
| Smart Phone | iPhone, iPad, Android |
| Brower | IE, Chrome, Firefox, Safiri |
| Intelligent Detection | Motion detection. Video loss, Video privacy, shelter alarm |
| Other | / |
| Network Interface | RJ45 10M/100M adaptive Ethernet port |
| POE Ports | 4x |
| Alarm input | / |
| Alarm output | / |
| RS-485 | Support |
| USB Port | 2*USB2.0 |
| e-SATA | / |
| HDD | 1 SATA, up to 8TB |
| Working Temperature | -20°C ~ 55°C/10﹪-90﹪ |
| Power Supply | DC48V/3A, POE |
| Power Consumption | NVR:<10W(Without HDD) |
| Dimension(mm) | NVR: 300(L)x209(W)x48.5(H)mm IPC: 66(W)*166.3(L)mm |
NVR Back Panel:
