Main Features:
-Built-in face recognition& smart searching functions
-Embedded Linux ensuring reliable operation
-16-channel IP camera input, real time recording up to 4K,
-Support 4 channel face recogntion IP camera
-Face database 3000, Black/white list trigger alarm output
-Support face comparison and recognition results query, face recognition results display in real time
-Automatic network replenishment(ANR), IP filtering for enhanced security
-H.265, H.264, VGA/HDMI output, HDMI 4K@30Hz, IPSAN, N+1 Hot backup,Recording watermark, RJ45
-4CH Alarm input/1CH Alarm output, 1ch RS485
-Two-way Audio talkback, USB3.0/USB2.0, RS485,
-2x SATA,
-8x POE Ports, DC48V
Datasheet:
| VIDEO | ||
| Network video input | 16CH | |
| Network access bandwidth | 80Mbps | |
| Video compression | H.265 /H.264 | |
| Video output | 1 CH VGA output（1920×1080@60HZ,1280×1024@60HZ） | |
| HD HDMI output（1920×1080@60HZ,1280×1024@60HZ） | ||
| Display mode | Synchronous output | |
| System mode | 16 digits +16 preview +9 playback+face recognition | |
| 32 digits +36 preview +9 playback | ||
| Video bit rate | 16-16000Kbps | |
| Video resolution | 5MP/4MP/3MP/1080P/960P/720P/D1/VGA/4CIF/DCIF/2CIF/CIF/QCIF | |
| Image display | 1/4/6/8/9/16 image display | |
| Snapshot mode | Support timing snapshot, manual snapshot, JPEG format | |
| Motion detection | Support 396(22*18) surveyed area can be set in every screen and multi-level sensitivity adjustable | |
| Privacy mask | Support 4 zones | |
| intelligent detection |
support IPC intelligent functions (target counting, Object left/lost, electronic fence, crossing detection,Humanoid detection, retrograde detection, Off duty detection,Electric vehicle) |
|
| FACE | ||
| Face Recognition Preview | Support face capture results display, recognition results display | |
| Access ability | Support front 4 channels access to face recognition camera | |
| Face database | Support built-in≤3000 faces; support B/W list layout control | |
| B/W list layout control | Support face B/W list alarm linkage | |
| Intelligent search | Support face retrieval by time period | |
| Support personnel list (whitelist, blacklist, stranger) query | ||
| Support local face database list to face search face | ||
| Support external face import, face search | ||
| Support video playback to manually capture face, face search | ||
| Support temperature screening (abnormal temperature, normal temperature, undetected) query | ||
| Support mask screening (mask not worn, mask worn, undetected) query | ||
| Face quality filtering | Face quality sub-threshold (0~10), the higher the value, the smaller the wrong grasp | |
| Face image quality (1~99) | ||
| Face tracking box | Hide face box, show face box | |
|
Face recognition parameter |
Face recognition minimum pixel |
≧80x80 |
| posture | Attitude pitch less than 25 degrees, around 30 degrees can be captured | |
| Shelter | Ordinary glasses, short sea, short brim has no effect on the snap | |
| expression | Normal slight expression does not affect the snap | |
|
Face recognition rate |
The recognition rate is above 95% | |
| Detection mode | Interval snapshot (interval time 1~10 seconds) | |
| Enter the snapshot (entering time 1~10 seconds), the number of snapshot (1~3) | ||
| Leave the snapshot (number of photos: 1~3) | ||
| Enter or leave | ||
| AUDIO | ||
| Audio compression | G.711u | |
| Audio input | 1 CH RCA port (IPC complex audio input) | |
| Audio output | 1 CH RCA port | |
| Bidirectional talk input | Bidirectional talk, RCA port | |
| VIDEO RECORDING AND PLAYBACK | ||
| Video frame rate | 1-30fps | |
| Record mode | manual/Timing record and alarm record/Timing record/alarm record/Stop record | |
| Playback ability | Support 9CH sub stream sync playback | |
| Playback mode | Instant playback, local record, Playback snapshot, external file playback | |
| Record search |
Time, calendar, channel search, event search, (ANR, regular video, motion detection video, alarm video, intelligent detection video) |
|
| Video playback |
Start time, play/pause, stop, forward, backward, single frame,forward 30 seconds, backward 30 seconds,fast play(1-256X), slow play(1-1/32X)、1/4/9 split screen, previous page, next page, backup, capture, show hidden progress bar, full screen,add face template,retrieve face info,roller amplification time bar precise playback |
|
| STORAGE AND BACKUP | ||
| Storage interface | 2*SATA | |
| HDD capacity | Single max.8TB | |
| Disk grouping | According video channels to set HDD quantity | |
| Disk quota | According video channels to set HDD storage capacity | |
| Backup location | Local, network, IPSAN | |
| Array type | / | |
| Hot-backup management | / | |
| Backup method | USB mobile hard disk, U disk, network backup | |
| ANR | Support Secumate IPC（with TF card）ANR | |
| FUNCTION | ||
| Network protocol | TCP/IP,HTTP,HTTPS,DDNS,SMTP(SSL),DHCP,PPPoE,UPnP,NTP,P2P | |
| Interface protocol | ONVIF、RTSP、 | |
| Protocol port | ONVIF/RTSP/HTTP/HTTPS/RTMP port customized | |
| Mobile surveillance | Support Apple, Android | |
| Internet explorer | Support IE, Chrome, Firefox, Safari | |
| Display function |
Channel shortcuts: modify the channel, 3D positioning, display AI intelligent rules and results, capture, voice intercom, channel audio, manual recording, instant playback, video parameters |
|
|
Desktop display: audio input, volume, alarm information (deployment/removal), P2P cloud service, network information,Output adjustment, system information, device list (showing whether IPC is online or not, recording type), organizational structure (custom channel classification for quick preview), channel round tour, 1/4/6/8/9/16/25/36 split screen, open round tour, open linkage preview, file backup、 full screen、Display face recognition,Face search,hide OSD、PTZ control, |
||
| IPC timing | Manual/auto/timing/reconnect timing to IPC timing | |
| Alarm linkage | Send email, audible warning（buzzer), alarm on monitor, upload to center, record, snapshot, preview, PTZ linkage | |
| Network detection | Flow monitoring, network wireshark, network test | |
| User management |
User add, delete, modify, permission management,FSLink Scan the QR code to retrieve the password |
|
| Auxiliary users(secondary password protection) | ||
| Manage IPC | Modify IPC parameters | |
| EXT INTERFACE | ||
| Network interface | 1*RJ45 100M1000M adaptive Ethernet port | |
| POE interface | 8CH（IEEE 802.3af）Max. power output≤80W | |
| Alarm input | 4CH | |
| Alarm output | 1CH | |
| RS-485 | 1CH | |
| USB Port | Rear panel:2*USB2.0 | |
| GENERAL | ||
| Power supply | DC48V/3A（Power plug specification optional） | |
| Power consumption | ≤10W（Without HDD） | |
| temperature/ humidity | -10°C ~ 55°C/10﹪-90﹪ | |
| Dimension(mm) | 360(L)x242.4(W)x48(H)mm | |
| Weight/PCS(g) (without HDD) | 2KG（Without HDD） | |
